TVR-3000VA electronic voltage stabilizer
Main Features
●Automatic voltage regulation
●Protection against Low voltage & over voltage
●Wide input voltage range
●Short circuit & over load protection
●Selectable delay time
●Built-in transformer: servo motor
●Anolog display
|
Specification |
TVR-0.5K |
TVR-1K |
TVR-1.5K |
TVR-2K |
TVR-3K |
TVR-5K |
STVR-8K |
TVR-10K |
TVR-12K |
|
|
Input |
Phase |
Single phase |
||||||||
|
Voltage |
AC150V-250V/50V-130V |
|||||||||
|
Frequency |
50HZ±2% |
|||||||||
|
Output |
Voltage |
220V±3%,110V±6% |
||||||||
|
power factor |
0.8 |
|||||||||
|
Frequency |
50HZ±2% |
|||||||||
|
Protection |
Under Volt. |
AC184±4V |
||||||||
|
Over Volt. |
AC246V±4V |
|||||||||
|
Delay |
3-7sec/3-7min(Optional) |
|||||||||
|
Over load /short circuit |
Yes |
|||||||||
|
Packaging |
Pcs Per Carton |
|
|
1 |
||||||
|
Shipping Wt.(kg) |
|
|
|
|
|
|
|
|||
|
Dimensions(mm) |
|
|
|
|||||||
|
Efficiency |
AC-AC |
>90% |
||||||||
|
Acoustic |
Noise level |
≤50dB |
||||||||
|
|
Temperature |
-5℃～45℃ |
||||||||
|
Humidity |
20% to 90% |
|||||||||
