LLFZ-E-NC Statistical Control Slitter Rewinder
Features:
1.lift, clamp and adjust the base paper with intelligent memory machinery, improve productivity and save labor.
2.adopt Japanese NSK in the bearings,with perfect transmitting effect after all the transmission rollers treated by balance adjustment.
3.adopt color man-machine interface and special-purpose operating system, easy to operate.
4.control tension-controlling system with statistical process control without manual, perfect slitting effect.
5.automatically slit the paper
6.assemble the edge-guiding assembly.
Technical parameters :
applicable base paper width: 1600mm
applicable base paper diameter: 1500mm
roll paper diameter: 1500mm
min slitting width: 50MM
base paper clamp without shaft: 1set(3INCH)
brake assembly: 2sets
tension advice with statistical control: 1set
main motor(Simens?converter): 15KW
power of knives assembly machinery: 0.75KW
lift machinery of base paper: 0.75KW
clamp machineries of base paper: 0.55KW(two)
separate electric operating box: 1set
emergency non-separate electric operating box: 1set
sets of score knives: 17sets(changeable)
power of edge-attracting blower: 4KW
slitting speed: 350m/min
