Features:
1. the inside diameter range from 30mm to 200mm , thickness up to 15mm .
2.adopt spiral bevel gear, stable.
3.assemble the imitate-Japanese newest wax-lubrication system, firm the friction between tubes and mandrel, easily control tubes' spiral seam, improve the tubes qualities, maintain the original color of the bottom-ply.
4.enlarge beam, even force on belt and tubes contact surface, improve the smoothness of tubes surface.
5.multi-plies paper frame, with long beam, improve the smoothness.
6.beam is manufactured by aging treated cast-iron, durable, without deformed.
7.expandable flange mandrel, taper core rob.
8.high-speed and low-resistance cutting system, smooth, low-waste.
9.changeable speed.
10.additional circular-blades cutting system.
11.circuit and electric appliances designed and installed by the international standard.
Specification :
inside diameter: 30 -200mm
max thickness: 15mm
Machinery speed: up to 15m /min
length: 1 -4m (custom-built)
power of main Motor: 11kw
power of cutting Motor: 2.2kw
power of circular-blades cutting: 0.75kw(non-assembly)
power of wax-lubrication machinery: 0.8kw size: 5100 1100 1900(mm)
