LLSG-D Digital Control Paper Tube Recutter
Features:
LLSG-D digital control paper tube cutter, with ease man-machine contact surface and convenient operation, adopts advanced colored touch-screen to input, display and PLC control. Inputting the cutting specification in advance, the cutting range is from 1mm to 2100mm . It is an ideal advanced paper tube cutter with high precision, proper structure, stable properties, reliable quality and smooth slit. It is the ideal machine for film industrial tubes with international advanced level. It is a high output machine for saving the time and the difficulty in adjusting the blades.
Technical parameters :
applicable inside diameter: 70mm -- 152mm
max length of parent tubes: 1600mm
cutted length: 10 -1600mm
applicable thickness: 5 -15mm
speed: 200mm /sec (changed by the thickness)
moving speed of blades frame: 200mm /sec
air pressure: 0.4-0.5Mpa
max measurement of used air: 1cubic meter/min
cutting accuracy: 0.2mm
power of main machinery: 2.85KW
power of servo machinery: 0.75KW
operator: 1 person
size: 1230 580 3240 (mm)
